Orange Peeler Industrial - Orange Peeler for Industrial Use
Orange Peeler Industrial
This industrial peeling machine makes it easy to peel any oval fruit, optimizes production processes and generates greater productivity. Its automation system allows you to peel various types of skin, with speed options for the blade movement, thus including thicker fruits and vegetables in production. It also incorporates a safety system that facilitates automatic stopping. . Its easy design provides wide configurability when carrying out the project.
General characteristics
Speed, efficiency and simplicity
Electropneumatic machine.
Allows quick and safe cleaning by using warm water and a cloth. Recommended daily cleaning.
Peels any type of fruit and vegetable that has a spherical or oval shape with 140 mm in diameter.
Optional square skin cut (Fixed Blade).
Two rotating tridents for better holding of fruits and foods.
Cylinder with positioner (feeling tube) to adjust the thickness of the blade cut.
Metal structure support on wheels with lock that allows easy movement of the machine.
Technical characteristics
PRODUCTIVITY
Thick-skinned fruits 6-7 units/min Thin skin fruits 12 units/min
DIMENSIONS
Machine 590 x 670 x 440 mm Support 900 x 700 x 500 mm
WEIGHT
220 kg
VOLTAGE
220/240 V – 50/60 Hz 110/120V – 50/60Hz
CONSUMPTION
70W
AIR PRESSURE
6KG
MATERIAL
304 stainless steel
BLADE DURABILITY
100,000 peeling cycles approx.
CUT THICKNESS
Between 1.5-6 mm approx.
FRUIT SIZE
Between 60-140 mm
SETTINGS OPTIONS
Superfine cutting thickness 0.2-1.5 mm Fixed blade cutting thickness between 2-10 mm and width of 2-8 mm Small fruits dimensions between 30-80 mm Large fruits, dimensions between 85-160 mm
